Technology type |
Basic parameters |
Extended parameters |
|
Product application field |
Military and Industry |
|
|
Protocol |
PCIe 3.0x4,NVMe 1.3 |
|
|
Dimension |
(22*60/80*3.85mm) |
|
|
Interface |
NGFF |
|
|
Controller |
SM2262EN /STAR1000P |
|
|
Flash type |
Toshiba/Intel/Micron 3D TLC |
|
|
Capacity |
3D TLC:256GB-2TB |
|
|
Read Performance (MAX) |
3100 MB/s |
|
|
Write Performance (MAX) |
3400 MB/s |
|
|
Power supply |
3.3V |
3.15V-3.4V |
|
Active/ Idle power consumption |
7.3W /0.78W |
|
|
Operating temperature |
-40~85℃ |
|
|
Weight |
<100g |
|
|
CE FCC ROHS |
|
|
|
Specific function |
Overload protection |
|
|
Encryption |
AES 128/256 |
|
|
Bad block management |
support |
|
|
Wear-Leveling |
support |
|
|
Write amplification |
1~2 |
|
|
MTBF |
1,000,000h |
|
|
Warranty |
3 years |
|
|
Humidity |
5%-95% |
|
|
Shock |
Operation 50G |
|
|
Vibration |
5G,10~2000Hz |
|
|
Reinforce |
support |
Customizable |
|
Model |
256GB |
512GB |
1TB |
2TB |
|
Active |
4W |
4W |
5.7W |
7.3W |
|
Idle |
0.75W |
0.75W |
1.6W |
1.7W |
Table 2 Performance
|
Capacity |
Max Seq. Read |
Max Seq.Write |
Avg Seq. Read |
Avg Seq. Write |
|
256GB |
1700 MB/s |
1500 MB/s |
1540 MB/s |
400 MB/s |
|
512GB |
1880 MB/s |
1790 MB/s |
1550 MB/s |
571 MB/s |
|
1TB |
3400 MB/s |
3001 MB/s |
2820 MB/s |
912 MB/s |
|
2TB |
3436 MB/s |
3125 MB/s |
2856 MB/s |
1301 MB/s |
